Young’s Modulus Apparatus – Vernier Type

This precision Young’s Modulus Apparatus is designed for the experimental determination of the relationship between applied load and extension in a wire, helping students explore key concepts in elasticity and material properties.

The setup includes a 10 cm engraved brass scale with a vernier that reads to 0.1 mm, allowing accurate measurement of wire elongation under tension. Supplied with a tension weight, this apparatus is ideal for physics labs studying stress, strain, and Hooke’s Law.

Key Features:

• Vernier scale reads to 0.1 mm for precise measurement
• 10 cm engraved brass scale for durability and accuracy
• Includes tension weight for applying a consistent load
• Ideal for investigating Young’s modulus of various wire materials
• Suitable for secondary and tertiary physics education

Applications:

• Measurement of stress and strain
• Experimental determination of Young’s Modulus
• Demonstrations of Hooke’s Law and elastic behaviour of materials
• Senior school and university physics labs
